SATEC’s eXpertMeter™ EM133-XM has been designed and tested to comply with the new Power of Choice reforms.
The eXpertMeter EM133-XM complies with the National Electricity Rules (NER) and AEMO Metrology Policies.
Additionally, the EM133-XM exceeds the Minimum Services Specification required for Power of Choice compliance.
There is a broad range of testing requirements for electricity energy meters. This is both complex and involves a lengthy testing procedure to ensure certified compliance.
National Measurement Institute – MNI M6-1
National Electricity Rules (NER) – Chapter 7
AEMO Metrology Policy – Part A
Minimum Services Specification
Market Settlement Data (Load Survey Files) 5-min, 15-min, 30-min
Remote Disconnect – Load Control – Demand Side Participation
Class 0.5S Accuracy according to AS/IEC 62053-22
AS/IEC 62052-11
SATEC innovations provide flexibility for metering installations compared to the current challenges with existing designs.
AEMO – Type 2, Type 3, Type 4, Type 5
NITP 14 – National Instrument Test Procedures
ISO 17025 certified laboratory
5 Year Warranty – 5 Year Accuracy Guarantee
Accuracy Class 0.5S – Whole Current & CT versions
Three-Phase or 3x Single-Phase configurable
Embedded Programmable Logic Controller (PLC) for Advanced Functionality
eXpertPower – RESTful API integration with JSON
MV-90 xi communication protocol for Meter Data Providers
Data logging in metering is known as Interval Data or Load Survey Files, otherwise referenced as Market Settlements Data.
8MB – EEPROM memory
1-Minutes, 2-Minutes, 3-Minutes, 4-Minutes 5-Minutes, 10-Minutes, 15-Minutes, 20-Minutes, 30-Minutes, 60-Minutes (Configurable)
Three (3) Interval Data Logs for EM133-XM
Up to forty-eight (48) electrical time/date stamped data records
Power Quality Logging
Voltage Interruptions, Sag/Swell, Overcurrent, Reverse Energy
eXpertPower – NEM12 reports – FTP, SFTP, email, RESTful API
A multi-function DIN-rail mounted kWh meter suitable for sub-metering for the Australian Market. *Dimensions: 125mm (width), 90mm (height)
Single phase or 3‑phase power metering, revenue metering and basic power quality information.
57 to 400V AC, up to 100A direct current measurement, connection of standard 5/10A CTs.
From residential energy metering, through industrial energy and harmonic analysis through utility comprehensive substation automation.
Communications in metering hardware supports remote reads, reprogramming, diagnostics and analysis, as well as demand side participation requirements.
Fully Supported
RS-485 (standard)
InfraRed (standard)
Ethernet TCP/IP (option)
WiFi (option)
3G integrated modem (option)
4G integrated modem (option)
RS-232/RS-422 (option)
Dual Communications
2x RS-485 (option)
1x RS-485 + 1x WiFi (option)
1x RS-485 + 1x 3G combined with 2x Analogue Inputs (option)
1x RS-485 + 1x RS-232/RS-422 (option)
1x RS-485 + 1x Ethernet TCP/IP (option)
1x RS-485 + 1x 3G (option)
1x RS-485 + 1x 4G (option)
The SATEC EM133-XM eXpertMeter provides communication protocol support for:
MV-90 xi TIM file
Modbus RTU
Modbus ASCII
Modbus TCP
IEC 60870-5-101
IEC 60870-5-104
CAN bus
Profibus DP
Advanced Functionality: Automation & Control
Embedded Programmable Logic Controller (PLC)
Single Cycle Processing Power – 20ms @ 50hz
Sixteen (16) individual programmable control functions
Digital Inputs & Relay/Digital Outputs for Control Automation
Configurable I/O – normally open, normally closed, negate logic, latching relays, KYZ pulse, etc.
Modbus TCP Notification service alarms – Meter Exception Reporting
16-bit & 32-bit data formats
120x Assignable Registers for Block Data Transfer efficiency in large systems
