SATEC’s new PRO assists with compliance to AEMO’s Market Ancillary Service Specification (MASS) for FCAS markets.
The PRO has two (2) separate models for either Real-Time Data or Internal Data Recording.
All FCAS markets are possible: Very Fast, Fast, Slow, Delayed & Regulation.
Accuracy Class 0.2S
0.0001 Hz
4 decimal places – Frequency
20 ms – Modbus RTU/TCP
1 second – Modbus RTU/TCP
1 second – IEC 61850 (0.001 Hz)
IEC 61557-12
NATA Test Certificates
Accuracy Class 0.2S
0.0001 Hz
4 decimal places – Frequency
1 second recording period
20 second before FDT and 10 minutes after FDT
IEC 61557-12
NATA Test Certificates
Accuracy Class 0.2S
0.0001 Hz
4 decimal places – Frequency
20 ms recording period
5 second before FDT and 60 seconds after FDT
IEC 61557-12
NATA Test Certificates
Market ancillary service specification compliance for recording period for Power & System Frequency Measurements
Class 0.2S accuracy according to IEC 62053-22
NATA Test Certificates
PLC embedded controller for advanced solutions
Dual Ethernet TCP/IP (standard)
RS-485 master/slave (standard)
USB C (standard)
InfraRed (standard)
4G CAT-M integrated modem (future)
IEC 61850 + GOOSE
Modbus RTU
Modbus ASCII
Modbus TCP
IEC 60870-5-101
IEC 60870-5-104
